Equipment
-
Light Conversion Pharos PH1-20W
20 W Ultrafast laser (230 fs pulses, 200 kHz PRF, 1030 nm) -
Light Conversion Orpheus HE
Collinear Optical Parametric Amplifier (315 nm - 16 µm) -
Iradion 1625
250 W CO2 laser (CW, 10.6 µm) -
Coherent Diamond J-3
250 W CO laser (CW, 5.5 µm) -
IPG YLR-500-AC
500 W Fiber Laser (CW, 1070 nm) -
ScanLabs exceliSCAN 14
Galvo scanner -
Aerotech ANT130XY/R, ATS100-150, and A3200
Precision 4-axis system (160-160-150 mm3 build volume, x/y: 75 nm repeatability, 350 mm/s, z: 700 nm repeatability, 100 mm/s, R: 1.5 arc-sec repeatability, 30 rpm) -
Optris PI640
Uncooled LWIR camera with integrated CO2 laser filter -
Epilog Legend 36EXT
120W CO2 laser cutting system (CW, 10.6 µm) -
View Benchmark
Metrology Microscope -
Zygo VeriFire
4" Interferometer -
Amscope ME520TC-18M3
Metallurgical Microscope -
Thermo Nicolet Nexus 670 with Continuµm Microscope
FTIR spectrometer -
Ando AQ6317B
Optical Spectrum Analyzer -
Type 36 Fusion Splicer
Fusion Splicer -
YSL SC-5
Supercontinuum Light Source -
LUNA ODiSI 6101
Optical Distributed Sensor Interrogator -
Bacher LS-100X-5CP
Deep UV light source -
Laurell WS-650MZ-23NPPB
Spin Coater -
Data Physics OCA 11
Optical Contact Angle Measurement System -
Texas Instruments DLP 6500
Digital Micromirror Device -
LC 2012 SLM
XGA Spatial Light Modulator -
MTI Unipol 1201
12" Precision Auto Lapping/Polishing Machine -
MTI SYJ160
Digital Low-Speed Diamond Saw -
Mark 10 F1505 Test Frame
Desktop UTM -
Phase II Rockwell Hardness Tester
Digital Rockwell Hardness Tester -
Sentro Tech ST-1800-666
High-temperature box furnace (1800ºC)
Miscellaneous
Several other laser systems, sensors, and optics instrumentation
Access to ND Nanofabrication Facility, ND Materials Characterization Facility, and ND Integrated Imaging Facilities
